Anping Hand in Hand factory direct hot-dip galvanized temporary fence panels for construction site procurement: building site hoarding, road works barrier, infrastructure project perimeter, demolition exclusion, public event barrier. AS 4687 / EN 12811 compliant; 2.1 x 3.5 m or 2.0 x 3.5 m standard, custom panel size, anti-climb and anti-lift options, 14 kg base block.
Get my construction site fence quote Send a detailed RFQ
- AS 4687 (Australia) and EN 12811 (Europe) temporary site fence compliance
- Hot-dip galvanized 70-86 micron zinc, 8-12 year outdoor service life
- 2.1 x 3.5 m or 2.0 x 3.5 m standard panel + anti-climb 2.4 m option
- 14 kg / 24 kg / 32 kg concrete base block, hook clamp connection
- Wind-load engineered: 800-1200 mm spacing per AS / NZS 1170 wind zone
- Container-load wholesale: 65 panels in 20GP, 130 panels in 40HQ
- RFQ replied by named engineer within one business day; full export packing
Recommended products: temporary construction fence panel manufacturer · galvanized welded wire mesh manufacturer · custom welded mesh panels for hoarding · perforated metal sheet for branded site banner.
Why wind-load, anti-climb and galvanized life decide site fence procurement
Construction site fence selection is governed by wind zone, public access risk, deployment cycles and storage between projects. The four mechanisms below decide panel size, frame and base block.
Wind load engineering
Site fence falls if wind load exceeds anchor capacity. AS / NZS 1170 specifies wind pressure by region; 14 kg base block holds 1100 mm panel at 24 m/s; 32 kg block needed for cyclone zone.
Anti-climb and anti-lift
Public site fence must prevent unauthorized entry. Anti-climb top with 50 mm dense mesh upper section + 30 mm hook locking; anti-lift bracket prevents panel removal without tool.
Hot-dip galvanized life
Site fence reused 50-100 cycles over 8-12 years. Hot-dip galvanizing 70-86 micron prevents rust at scratched edge and welded joint; powder coating optional for branded site appearance.
Quick-deploy connection
Hook clamp + base block + bracing for 200 m perimeter installable in 4 hours by 2 people. Modular layout for irregular site boundaries; corner panels and gate panels available.
Panel size, frame and base block guide for construction site fence
Engineers select panel size and base block by wind zone (AS / NZS 1170 / EN 1991), site type and reuse cycle requirement. Standard 2.1 x 3.5 m + 14 kg block for inland; 24-32 kg block + brace for cyclone / storm zone. temporary fence panel size selection guide · surface treatment selection guide · wire mesh buying guide and material comparison · Anping Hand in Hand factory capabilities.
| Use case | Panel size | Frame | Mesh | Base block / fixing |
|---|---|---|---|---|
| Building site hoarding | 2.1 x 3.5 m | Round tube 32 mm OD | 4 mm wire 60×150 mm opening | 14 kg concrete block |
| Road works barrier | 2.0 x 3.5 m | Round tube 32 mm OD | 3.5 mm wire 60×150 mm opening | 14 kg concrete block |
| Anti-climb perimeter | 2.4 x 3.5 m | Round tube 38 mm OD | 4 mm wire upper 30 mm dense | 24 kg concrete block + brace |
| Cyclone-zone site | 2.1 x 3.5 m | Round tube 38 mm OD | 4 mm wire 60×150 mm opening | 32 kg block + diagonal brace |
| Public event barrier | 1.2 x 2.5 m | Round tube 32 mm OD | 3 mm wire 60×150 mm opening | 14 kg block or steel foot |
| Custom branded panel | per drawing | square tube + powder coat | 4 mm wire mesh + scrim banner | standard or custom block |
Construction site fence application zones
Six standard procurement scenarios with recommended panel size, frame and base block, and expected service life. Send the zone plus your country wind-zone code and our engineer confirms spec.
Building site hoarding
Recommended: 2.1 x 3.5 m hot-dip galvanized temporary fence panel
Spec: Round tube 32 mm OD frame + 4 mm welded wire 60×150 mm opening + 14 kg concrete base
Major building project perimeter (high-rise, hospital, school). Anti-climb option for public-facing sides; quick-deploy 200 m / 4 hr 2 person.
Service life: 8-12 years
Road works and traffic barrier
Recommended: 2.0 x 3.5 m galvanized fence panel
Spec: Round tube 32 mm + 3.5 mm wire 60×150 mm + 14 kg block + reflective tape strips
Highway lane closure, urban road repair, utility excavation. Reflective tape per AS 1742 traffic management; standard road works visibility.
Service life: 8-12 years
Demolition exclusion
Recommended: Anti-climb 2.4 m fence panel + scrim
Spec: Round tube 38 mm + 4 mm wire 30 mm dense top mesh + 24 kg block + diagonal brace
Demolition zone, asbestos removal, high-risk excavation. Anti-climb upper section + privacy scrim banner; bracket to prevent panel lift.
Service life: 10-15 years
Infrastructure project perimeter
Recommended: 2.1 x 3.5 m + branded scrim banner option
Spec: Powder-coated panels in safety yellow / blue / corporate color; 4 mm wire 60×150 opening
Bridge, tunnel, dam, airport, port project perimeter. Branded scrim with project logo or safety messaging; custom panel color.
Service life: 10-15 years
Public event and venue barrier
Recommended: 1.2 x 2.5 m crowd control fence panel
Spec: Round tube 32 mm + 3 mm wire 60×150 mm; steel foot or 14 kg base block
Concert, sport event, festival, ceremonial route. Lighter portable panels; quick foot stand for hard surface; storage cart available.
Service life: 8-12 years
Cyclone and storm-zone site
Recommended: Heavy-duty 2.1 x 3.5 m fence + 32 kg base + brace
Spec: Round tube 38 mm + 4 mm wire + 32 kg concrete block + diagonal anchor brace
Coastal Australia, Caribbean, US Gulf Coast, Philippines, Japan typhoon zone. Wind-load to 50 m/s; brace per AS / NZS 1170.
Service life: 8-12 years
Recommended Anping Hand in Hand products for construction site fence procurement
Each product page covers full specifications, opening size, wire diameter, panel size, and pricing for FOB Tianjin, CIF, DAP and DDP. RFQ is replied within one business day by a named engineer.
- temporary construction fence panel manufacturer
- galvanized welded wire mesh manufacturer
- custom welded mesh panels for hoarding
- perforated metal sheet for branded site banner
Sibling application pages: marine and coastal 316 stainless wire mesh · factory equipment guard mesh selection · farm and aquaculture fencing wire mesh · wire mesh application gallery.
Construction site fence procurement FAQ
Common procurement questions answered up front. Bulk wholesale buyers see request a construction site fence quote or contact Anping factory team.
What standards do your construction site fence panels comply with?
AS 4687 (Australian temporary fencing standard for events and construction), EN 12811-1 (European temporary works for construction), and BS 1722-10 (UK steel railing). Hot-dip galvanizing per ASTM A123 / ISO 1461. Wind-load engineered to AS / NZS 1170. Mill test certificate and zinc thickness record supplied.
What is the standard panel size and weight?
Standard panel: 2.1 m height x 3.5 m length, 4 mm wire mesh, 32 mm OD round tube frame, hot-dip galvanized. Panel weight: 18-22 kg. With 14 kg base block and hook clamp: total per unit ~36 kg. Container loading: 65 panels in 20GP, 130 panels in 40HQ.
What anti-climb options do you supply?
Anti-climb top section with 30 mm dense mesh in upper 600 mm; total panel height 2.4 m. Anti-lift bracket prevents panel removal without tool. Privacy scrim banner attaches via cable ties. Spike top option (carefully balanced with public safety) for high-security site.
Can you supply branded / colored panels?
Yes. Powder coat in any RAL color over hot-dip galvanized base (corporate brand color, safety yellow, sky blue). Scrim banner with logo or safety messaging clipped to mesh face. Color-matched base block painting on request.
What is the wind-load rating of your fence?
Standard 14 kg base block holds 2.1 x 3.5 m panel to 24 m/s wind speed (about 87 km/h). 24 kg block: 32 m/s. 32 kg block + diagonal brace: 50 m/s (cyclone zone). Wind-load calculation per AS / NZS 1170 supplied with quotation.
What is the typical service life of a hot-dip galvanized site fence?
8-12 years through 50-100 deploy / store cycles. Indoor storage between deployments extends life. Powder coating over galvanized adds 3-5 years. Coastal exposure shortens life to 5-8 years; switch to additional coating or stainless coupling.
What is the MOQ and what do you ship in one container?
MOQ: 1 x 20GP container (65 panels + 65 base blocks + 65 hook clamps + accessories). 1 x 40HQ: 130 panels. For projects below MOQ, mixed-load with other Anping fence products (chain link, welded mesh) is available. Sample panel reviewed case by case.
Do you supply fence panels to AS 4687 Australian standard?
Yes. AS 4687 compliance for Australian construction and event temporary fencing: 2.1 m height, anti-climb option, wind-load to AS / NZS 1170, hot-dip galvanized to AS / NZS 4680. Australian buyers regularly ship from Anping; container transit Tianjin to Sydney 18-22 days.
Inside the Anping Hand in Hand factory – construction cf sourcing transparency
Temporary welded mesh fence panels and site hoarding for construction projects – galvanized fence panel production line, panel array, weld integrity detail and stock yard sourcing transparency at the Anping wire mesh factory. Buyers welcome to visit, video tour, or appoint SGS / BV / TUV third-party inspection. USCC 91131125MA7FT3EA0D.
Why buyers can trust Anping Hand in Hand on this order
Anping County, Hebei Province is the national wire mesh production cluster of China with 4000+ wire mesh enterprises within 30 km. Our workshop, warehouse and shipping yard back every quotation with physical evidence buyers can verify on site, by video call, or via SGS / BV / TUV inspection.
He Zhanbing
Senior Application Engineer | Anping Hand in Hand
5 years on the wire mesh and steel grating production line. Reviews drawings, opening specifications, panel size, finish and packing. Replies within one business day with binding pricing, weight per panel and lead time. Confirms grade selection (304 / 316 / 316L / duplex / 65Mn / Q235) against your application before quotation.
Verified legal entity and buyer-checkable records
Registered name (EN): Anping Hand in Hand Wire Mesh Products Co., Ltd.
Registered name (CN): 安平县手拉手丝网制品有限公司
Unified Social Credit Code (USCC): 91131125MA7FT3EA0D
Registered address: Anping County, Hebei Province, China
Geo coordinates: Lat 38.2314 / Lng 115.6253 (Anping wire mesh cluster)
Buyers may request a legal entity check, on-site visit appointment, video factory tour, or third-party (SGS / BV / TUV) inspection before payment. Quotations and contracts are issued under the registered legal entity above. Mill test certificate (MTC) traceable to wire batch number supplied by default; ASTM B117 salt-spray, ASTM E8 tensile and ISO 9227 reports supplied on request.
Business license (click to view full size)
Standards we work to: ASTM A123 / A153 (hot-dip galvanizing), ASTM A580 / A480 (stainless steel grade), ASTM E8 (tensile), ASTM B117 (salt-spray), ISO 9227 (NSS), ISO 9001 (quality management — in renewal cycle), EN 10204 type 3.1 (mill cert), EN 10088 (stainless), EN 1461 (galvanizing), EN 10218 (steel wire), AS 4687 / EN 12811 (construction fence), AS 1657 (walkway), ISO 13857 (machine guard), NACE MR0175 / ISO 15156 (sour service).
Get a same day construction site fence quote
Send the form below or WhatsApp +86 15075801841 for a same day reply. Drawings (2D / 3D / STEP) and salt-spray test requirements welcome.
Engineering reference: see our steel grating load capacity and span selection guide for ANSI/NAAMM MBG 531 load tables, span formulas and a 5-step procurement workflow.
Manufacturer evidence and quality control
The construction site fence panels described on this page is manufactured at our Anping County, Hebei factory (USCC 91131125MA7FT3EA0D) by Anping Hand in Hand Wire Mesh Products Co., Ltd. Mill cert per EN 10204 type 3.1 issued for every order; type 3.2 third-party witness inspection (SGS / BV / TUV / Lloyds) on request.
Manufacturer: Anping Hand in Hand Wire Mesh Products Co., Ltd. (USCC 91131125MA7FT3EA0D) →
Compatible equipment and standards systems
Our wire mesh is produced to fit the dimensions, hook strip, framing standards, or test profiles published by the following equipment manufacturers and standards bodies. Send us your system or screen model number with your RFQ and we will quote against the corresponding spec.
Brand names are property of their respective owners; listed for product compatibility / standards identification only. Anping Hand in Hand Wire Mesh Products Co., Ltd. (USCC 91131125MA7FT3EA0D) is an independent wire mesh manufacturer and is not affiliated with these brands or systems.
What you receive with every shipment
Every container we ship arrives with a complete document set so your QA, customs broker, and goods-in team have nothing to chase.
- ✓Mill test certificate (EN 10204 type 3.1) — Heat number, chemical composition, mechanical properties — issued for every order
- ✓Dimensional QC measurement record — Per-product critical dimensions verified against your approved drawing — measured against your approved drawing
- ✓Packing list with PO traceability — Roll / panel / sheet count, m² per unit, total weight, container loading sequence
- ✓Bill of lading (FOB Tianjin Xingang or Qingdao) — For your customs broker and freight forwarder
- ✓Country of origin certificate — Form A / Form E available for AU / NZ / Korea / RCEP markets
- ✓Sample inspection cert from SGS / BV / TUV / Lloyds — Type 3.2 third-party witness inspection on request, paid by buyer
Want to see a redacted sample document set before you place an order? Message engineer He Zhanbing on WhatsApp and he will email you a desensitized type 3.1 mill cert and SGS test report within one working day.
Export-ready capability for first-time international buyers
We are an Anping County, Hebei manufacturer prepared to handle full international procurement documentation in English — mill cert, packing list, BoL, country-of-origin form, freight forwarder coordination from Tianjin Xingang or Qingdao. Whether this is your first import from China or your fiftieth, our process is the same.
New buyer? Request a 5 m sample roll first; we ship by FedEx / DHL with a redacted EN 10204 type 3.1 mill cert so your QA team can validate before placing a container order.
